CANnon is a fully isolated USB-to-CAN FD bridge powered by the STM32G0B1. Optional BLE connectivity allows for wireless bus monitoring.
Microcontroller
STM32G0B1CBT6
Cortex-M0+ @ 64MHz
USB Interface
USB-C PD + FS
Supports PD negotiation & 12Mbps Data
Isolated CAN
ISO1044BDR
Isolated CAN FD Transceiver
Isolated Power
TI SN6505
Low-Noise Transformer Driver
Bluetooth Low Energy
BlueNRG-M0L
BLE v4.2 via SPI
Buck Regulator
TPS62932
High Efficiency Wide VIN
HW Version V1.0
